Bottom Line
Treat the scar pattern, not the device. A narrow ice-pick scar, a tethered rolling scar, a boxcar scar and a raised scar are different clinical problems. The useful question is which treatment mechanism matches the scar and the patient's skin, not which technology sounds strongest.
Key Takeaways
When I assess acne scars, I do not start by choosing a machine. I first ask what is actually creating the visible irregularity. Is the scar narrow and deep, broad and tethered, sharply edged, raised, or mainly a colour change? Once that is clear, the treatment becomes a clinical decision rather than a technology-shopping exercise.
Dr. D's perspective

1. What Are Acne Scars, and Why Does the Type Matter?
An acne scar is a lasting structural change in the skin that can remain after inflammation from acne has healed. Most facial acne scars are atrophic, meaning the skin has lost or altered supporting tissue and leaves a depression. Hypertrophic scars and keloids are raised because excess scar tissue has formed.[4][8]
A second distinction is between a true scar and a flat mark. Red or pink areas may represent post-inflammatory erythema, while brown or grey-brown areas may represent post-inflammatory hyperpigmentation. These marks can improve over time and may require a different strategy from a scar that changes the contour of the skin.[1][4]
Active acne also matters. If new breakouts continue, they can create new scars while older scars are being treated. The American Academy of Dermatology recommends addressing active acne as part of the overall treatment plan.[1]
2. What Are the Main Acne-Scar Patterns?
Acne Scar Types: What the Surface Tells You
Ice-Pick
Narrow, deep, V-shaped depression. Often needs focal treatment rather than broad resurfacing alone.
Boxcar
Wider depression with sharper edges. Resurfacing can help; deeper or sharply edged scars may need combination treatment.
Rolling
Broad, shallow depression with sloping edges. Tethering beneath the scar can matter; lifting procedures may be considered.
Raised / Keloid
Scar tissue rises above the skin surface. Different treatment pathway from depressed scars; assessment is important.
Important: flat red/brown marks after acne are often post-inflammatory colour changes, not true scars.
Figure 1. Common acne-scar patterns. The illustration is schematic and is not intended for self-diagnosis.
Ice-Pick Scars
These are narrow, deep depressions that can extend further into the skin than they are wide. Because their geometry is focal, broad resurfacing alone may not fully address the depth. A clinician may consider a focal technique for selected scars.
Boxcar Scars
Boxcar scars are wider depressions with relatively distinct edges. They can be shallow or deep. Resurfacing or needling approaches may help selected scars, while deeper or sharply defined scars may need a more targeted or combined plan.[4][8]
Rolling Scars
Rolling scars are broad depressions with sloping edges. Some are influenced by fibrous bands that tether the skin to deeper tissue. When tethering is a major component, a lifting procedure such as subcision may be considered alongside resurfacing or another treatment.[4][8]
Raised Scars and Mixed Problems
Hypertrophic scars and keloids follow a different treatment pathway from depressed scars and may require injections, laser treatment, cryotherapy, surgery or combinations depending on the diagnosis. Many patients also have mixed scar types plus redness or pigmentation, which is why one treatment may not address every visible concern.[1][4]
3. What Treatments Can Improve Acne Scars?
Several procedures can improve the appearance of atrophic acne scars. They are not interchangeable, and the evidence for a treatment category should not automatically be treated as proof that every device or protocol within that category works equally well. The most appropriate approach depends on scar morphology, skin characteristics, treatment intensity and clinical experience.[1][9][12]
Fractional CO₂ Laser
Fractional CO₂ is an ablative resurfacing treatment. It creates microscopic columns of controlled thermal injury while leaving surrounding skin available for healing. The resulting wound-healing response can promote collagen remodelling and improve the appearance of atrophic scars.[6][7][9]
The trade-off is treatment intensity. Fractional CO₂ can produce more visible recovery and a greater concern about pigmentary change than some less aggressive approaches. In darker skin, treatment settings and patient selection are especially important.[7][12][13]
Fractional Radiofrequency Microneedling
RF microneedling combines mechanical needling with radiofrequency energy delivered at controlled depths. This allows treatment to target the dermis while limiting some of the surface disruption associated with ablative resurfacing. Systematic reviews support RF microneedling as a useful option for atrophic acne scars, while also noting that treatment parameters and study quality vary.[10][11][12]
Medical Microneedling
Medical microneedling uses small needles to create controlled micro-injuries that stimulate collagen production during healing. The AAD describes microneedling as minimally invasive and suitable for all skin tones when properly performed. Results develop gradually and a series of treatments may be needed.[2]
Focal and Lifting Procedures
Some scars are driven by a structural problem that a surface treatment cannot fully correct. Focal techniques may be considered for selected ice-pick scars, while subcision may be considered when fibrous tethering contributes to rolling scars. These procedures can also be combined with resurfacing or needling when the scar has more than one component.[1][4][8]
PRP as an Adjunct
Platelet-rich plasma is commonly discussed as a complementary treatment. Reviews suggest that adding PRP to procedures such as microneedling or laser treatment may improve some outcomes, but protocols differ and the evidence is not uniform. It is better understood as an adjunct selected for particular treatment plans rather than a universal stand-alone solution.[1][14][15]
Treatment Mechanisms at a Glance
Fractional CO₂ Laser
Ablative fractional resurfacing. Targets epidermis and dermis; stimulates collagen remodelling.
Morpheus8
Fractional RF microneedling. Needles deliver RF heat at controlled depths to remodel dermal tissue.
Sylfirm X
Dual-wave RF microneedling. Pulsed/continuous wave modes; device-specific evidence is still developing.
Medical Microneedling
Collagen-induction needling. Controlled micro-injuries stimulate wound healing and new collagen.
PRP
Autologous biologic adjunct. May be combined with needling or laser to support healing outcomes.
These are broad categories, not guarantees of outcome or fixed treatment protocols.
Figure 2. Broad treatment mechanisms used in acne-scar care. The diagram explains mechanisms, not guaranteed outcomes or fixed treatment protocols.
4. How Do the Main Treatment Approaches Differ?
The table below is a clinical comparison, not a ranking. More recovery does not mean better treatment, and less recovery does not mean a treatment is more suitable. The trade-off depends on scar depth, morphology, skin type, treatment intensity and the patient's goals.[1][9][12]
| Approach | Main Mechanism | Often Considered For | Recovery / Risk Considerations | Evidence Context |
|---|---|---|---|---|
| Fractional CO₂ laser | Ablative fractional resurfacing | Atrophic scars, especially texture and contour | More visible recovery; PIH risk requires careful settings and aftercare | Established treatment category; protocols vary |
| RF microneedling | Needling plus RF energy in the dermis | Atrophic scars where remodelling with limited surface disruption is desired | Usually less surface disruption than ablative resurfacing; heat and needling still cause temporary inflammation | Supportive systematic-review evidence; device and settings matter |
| Medical microneedling | Controlled micro-injury and collagen induction | Mild-to-moderate atrophic scars; patients prioritising lower surface disruption | Usually limited recovery; often performed as a series | Supported by clinical studies and dermatology guidance |
| Focal / lifting procedures | Targeted release or treatment of selected scar structures | Ice-pick scars or tethered rolling scars in selected patients | Procedure-specific risks and recovery; technique must match scar anatomy | Used selectively according to morphology |
| PRP adjunct | Autologous platelet concentrate used with another procedure | Selected combination plans | Adds blood-draw and treatment steps; protocol varies | Evidence suggests possible adjunctive benefit, but results are heterogeneous |
What About Deep Acne Scars?
Depth alone does not determine treatment. A deep ice-pick scar, a deep rolling scar with tethering and a deep boxcar scar have different structures. The shape, edges, tethering and surrounding skin are therefore more useful for treatment planning than the word 'deep' by itself.[4][8]
Is a More Powerful Treatment Always Better?
No. Increasing treatment intensity can increase tissue injury, recovery time and pigmentary risk. The appropriate intensity is the one that offers a reasonable expected benefit for the specific scar while keeping avoidable risks acceptable. This balance is especially important in patients with darker skin or a history of post-inflammatory hyperpigmentation.[7][13][16]
5. How Does a Doctor Choose a Treatment Plan?
A good acne-scar consultation is less about selecting a favourite device and more about answering a sequence of clinical questions. The doctor examines the scars from different angles, identifies the dominant scar patterns and separates contour problems from colour changes.
How Doctors Choose an Acne-Scar Treatment
Identify the Scar Pattern
Ice-pick, boxcar, rolling, raised/keloid, mixed.
Assess Skin Characteristics
Skin tone, pigmentation tendency, sensitivity, active acne.
Match the Treatment Mechanism
Resurface, remodel collagen, release tethering, lift/replace volume.
Balance Recovery & Risk
Downtime, PIH risk, infection risk, work/social schedule.
Build the Plan
One modality or a staged combination, with reassessment after healing.
There is no single 'best' treatment for every acne scar. Treatment is usually personalised.
Figure 3. A practical treatment-selection pathway: identify the scar pattern, assess skin and pigmentation tendency, match the treatment mechanism, balance recovery and risk, then build an individualised plan.
- Scar structure: Ice-pick, boxcar, rolling, raised or mixed.
- Skin type and pigmentation tendency: Especially previous post-inflammatory hyperpigmentation and how the skin responds to inflammation.
- Scar burden: Number, depth, distribution and whether active acne remains.
- Recovery needs: Work, social commitments, tolerance for redness, swelling or peeling, and the amount of aftercare required.
- Previous treatment: What has already been tried, how the skin responded and whether there were complications.
- Expectations: The degree of improvement the patient hopes to achieve and whether the goal is texture, contour, colour or a combination.
Clinical principle
Technology is selected according to your skin and scar pattern, not the other way around. Assessment comes first, then treatment mechanism, then the specific device or protocol.
6. What About Recovery, Risks and Darker Skin?
Fractional CO₂ Recovery
After ablative fractional laser treatment, redness, swelling, discomfort, crusting or peeling can occur. Recovery depends strongly on the treatment settings and the individual. Pigmentary changes, infection and prolonged redness are among the complications that need to be discussed before treatment.[3][7][13]
Microneedling and RF Microneedling Recovery
Microneedling and RF microneedling can cause temporary redness, swelling, tenderness or a rougher skin texture during healing. The exact recovery depends on needle depth, RF energy, treatment density and the patient's skin.[2][10][11]
Pigmentation Risk and Skin of Colour
Post-inflammatory hyperpigmentation is an important consideration in darker skin. It does not automatically mean that procedures should be avoided. It means treatment parameters, inflammation control, sun protection and patient selection need to be handled carefully. Reviews support the use of energy-based treatments and RF microneedling in skin of colour when appropriate settings are used, while also emphasising the need for more comparative data in darker phototypes.[12][13][16]
Aftercare Basics
- Follow the treating clinician's wound-care and skincare instructions.
- Use sun protection as directed, because ultraviolet exposure can worsen post-treatment pigmentation.
- Do not pick peeling skin or crusts.
- Report increasing pain, spreading redness, pus, fever, significant blistering or other unexpected symptoms.
- Continue acne treatment when advised, because new breakouts can create new scars.
7. What Should I Expect From Results?
Acne-scar improvement is usually gradual. Collagen remodelling continues after the visible surface has healed, so the final appearance can take weeks to months to become clear. Many patients need more than one treatment session, and a staged plan may be more appropriate than trying to correct every scar at once.[2][3][8]
The goal is generally to make scars less noticeable and improve skin texture or contour, not to promise complete removal. A 2026 systematic review comparing fractional CO₂ laser with needling-based approaches found broadly comparable efficacy across several measures but substantial variation between studies, while also finding a higher risk of post-inflammatory hyperpigmentation with fractional CO₂ than standard microneedling. This reinforces why patient and treatment factors matter when interpreting averages from studies.[16]
Realistic expectation
A meaningful result does not have to mean perfectly smooth skin. The more useful goal is improvement that matches the scar pattern, skin characteristics, treatment risk and the patient's expectations.
8. Frequently Asked Questions
9. Conclusion and Practical Next Step
Acne scars are structural problems, not one uniform condition. Ice-pick, boxcar, rolling and raised scars can require different treatment strategies, and many patients have more than one scar pattern or a mixture of contour and colour changes. Fractional CO₂ laser, RF microneedling, medical microneedling and focal procedures all have roles in selected patients, while PRP may be useful as an adjunct.[1][4][8][12]
The most useful question is therefore not 'Which device is strongest?' It is 'Which treatment mechanism matches my scar type, skin characteristics, treatment goals and tolerance for recovery?'
Educational next step
Before choosing a procedure, ask a qualified clinician to identify your scar types, explain why a particular treatment mechanism fits them, discuss the expected recovery and pigmentation risks, and clarify how active acne will be controlled during the treatment plan.
Sources & References
The following sources were used to verify the clinical, scientific and regulatory information in this article. Accessed/reviewed 26 September 2026.
- [1] American Academy of Dermatology Association. Acne scars: Consultation and treatment. Last updated 2023.
- [2] American Academy of Dermatology Association. Microneedling can fade scars, uneven skin tone, and more. Last updated 2023.
- [3] American Academy of Dermatology Association. Acne scars: How to care for your skin after treatment. Last updated 2023.
- [4] DermNet New Zealand. Acne scarring. 2023.
- [5] Jacob, C. I., Dover, J. S., & Kaminer, M. S. (2001). Acne scarring: A classification system and review of treatment options.
- [6] DermNet New Zealand. Fractional laser treatment. 2024.
- [7] DermNet New Zealand. Carbon dioxide laser treatment. 2024.
- [8] Bhargava, S., Cunha, P. R., Lee, J., & Kroumpouzos, G. (2018). Acne scarring management: Systematic review and evaluation of the evidence.
- [9] Salameh, F., et al. (2022). Energy-based devices for the treatment of acne scars: 2022 International consensus recommendations.
- [10] Forbat, E., & Al-Niaimi, F. (2016). Fractional radiofrequency treatment in acne scars: Systematic review of current evidence.
- [11] Li, J., Duan, F., & Kuang, J. (2022). Meta-analysis of fractional radiofrequency treatment for acne and/or acne scars.
- [12] Niaz, G., et al. (2025). Fractional radiofrequency microneedling as a monotherapy in acne scar management: A systematic review of current evidence.
- [13] Azzam, O. A., et al. (2022). Laser treatment of acne scarring in skin of colour.
- [14] Cruciani, M., et al. (2024). Platelet rich plasma use for treatment of acne scars: An overview of systematic reviews.
- [15] Abdel Hay, R., et al. (2022). Ablative fractional carbon dioxide laser combined with autologous platelet-rich plasma in the treatment of atrophic acne scars: A systematic review and meta-analysis.
- [16] Xiang, X., Shuai, W., & Mu, Y. (2026). Comparative efficacy and safety of fractional CO2 laser and gold microneedling radiofrequency for atrophic acne scars: A systematic review.
- [17] Batool, A., et al. (2026). Comparing fractional CO2 laser and needling-based modalities in facial acne scar treatment: A comprehensive systematic review and meta-analysis.
This article changes as evidence, product approvals and regulations evolve. It is for general education, not personalised medical advice, so always confirm your own suitability, risks and options with a qualified doctor.
